CNC Vertical Machining Center
-
-
Index Unit XKVM1800 Workbench size mm 2200×600 Workbench saddle matching width mm 500 Max. load of workbench kg 2000 T slot (number×width×distance) mm 5×18×100 X-axis travel mm 1800 Y-axis travel mm 700 Z-axis travel mm 750 Spindle end to bench top mm 125~875 Spindle center to column mm 700 Bed rail width mm 1100 Spindle taper hole size BT50 Tool change mode Vertical disc tool magazine 24T Spindle speed rpm 80~6000 Spindle motor power kW 18.5 X-axis screw 5010 Y, Z-axis screw 5010 -
